Max. Pressure

10 metric tons Max.
Pressure gauge is built in

Gauge Pressure Value to Force Conversion

1.       Notes:

2.       Displayed Pressure Value to Actual Applied Force Conversion: 1 MPa = 0.6 Ton

3.       The actual force applied on the Hydraulic Cylinder (Ton) equal to the force applied on your working piece

4.       For calculating the actual pressure (MPa) applied on your working piece, please follow the equations in below:

          P = T/(πr^2) x g x 10

1.       P: Pressure (MPa) applied on your working piece

2.       T: Force (Ton) applied on the Hydraulic Cylinder

3.       g: Standard gravity. g ≈ 9.8 m/s²

4.       π: ~3.14

5.       r: Radius (cm) of the working piece

6.       *1 Metric Ton = 1000 kg; 1 MPa ≈ 10 kgf/cm²

Pump

Build-in Hydraulic Pump

Warranty

One year limited manufacturer warranty with lifetime support.

Bottom Hydraulic Cylinder Travel Distance

Standard 0-120 mm, opitional other distance

Max Lifting Height

120mm

Dimensions of Machine

220*160*370mm

Compliance

CE Certified

Net Weight

19 kg

Press Dies

Pressing dies with various diameters(6-60mm Dia) are available upon request
