Chamber and Door

 1. The chamber is structured with stainless steel and welded to   bracing pieces.
 2. The inner Chamber size: 300 mm x 300 mm x 275 mm (12 x  12 x 12", 25 Liter)
 3. A good vacuum sealing is achieved by the silicone gasket   and the positive latch door.
 4. The double layers observation window consists of 1/2"   tempered glass and transparent polycarbonate shield.
 5. Two stainless steel shelves are included to facilitate   processing efficiency.

Vacuum Pump
(optional)

  Ultimate Vacuum Level: 1000 millitorrs.

Working Voltage

  AC 108 - 240 V 50/60 Hz

Input Power

  600W

Working Temperature

  RT+10 ~ 200°C for the continuous use

Temperature Controller

 1. Single point temperature setting
 2. Built-in over-temperature protection
 3. PID precise temperature control
 4. Temperature control accuracy: +/-0.1°C
 5. Temperature uniformity: +/-5°C @ 100°C, 25" Hg at center   6"x  6" area only

Fittings

 This oven comes with a KF-25 vacuum connector which allows   you set up a quick connection to the vacuum pump.

Compliance

 CE Certified

Warranty

 Two years limited warranty with lifetime technical support

Attention

 1. It's normal that the SS chamber wall will slightly deform and   loose its shine during high-temperature operation. However, this   would not affect any functionality.
 2. Please do not place the sample on the chamber bottom   directly.
