X-RAY Testing Machine for Internal Defect Detection

Ⅲ、Equipment component description：

3.1 Micro focus X-ray generator and control system;；

3.2 X-ray detection imaging system;

3.3 X-ray protection box;

3.4 Electrical control system;

3.5 Control PC and image processing;

3.6 Automatic power-off protection device;

3.7 Three color light equipment status reminder;

3.8 Photoelectric induction control device;

3.9 The metal plate and perspective window of the whole machine are embedded with lead plate to ensure radiation safety and prevent radiation leakage;

3.10 Navigation device;

Ⅳ、Process operation process requirements：

Ⅴ、General configuration and standard of equipment：

5.1  Equipment appearance color: warm gray 1C (or subject to the customer's color plate).

5.2  Measured 1m away from the equipment (operation position), the equipment noise is ≤ 75db.

5.3  The equipment complies with the safety standards of China for electromechanical equipment.

5.4 Size：L1200mm×W1100mm×H1830mm（The specific size shall be subject to the actual object）

5.5 Total weight: 760KG

5.6 Ambient temperature：25±3℃

5.7 Ambient humidity: ≤ 60% RH (no condensation)

5.8 Power：2.5KW
