UV sterilization machine can be used to sterilize the air and objects. Widely used in hospitals, food, tea and food and beverage packaging equipment, food factory, cosmetics factory, beverage factory, milk factory, brewery, bakery and freezer. And can prolong the shelf life of the products.

Working Principle:

This machine adopts Teflon mesh belt, the product can be directly on the mesh belt for sterilization, sterilization time to enter the regional network with the best about 1-3 minutes, thorough sterilization, sterilization effect, convenient operation and ideal practical effect.

Function:

1. With 16 sets of ultraviolet UV sterilization special tubes, sterilization in all directions.Uniform distribution in the furnace up and down the five, three, around each sterilization no dead Angle of 360 degrees all powerful antiseptic effect.
2. There a UV reflectors (inner box mirror stainless steel plate), the product through the sterilization, can greatly improve the utilization rate of up to 90% of UV light.
3. Each group germicidal lamp can separate control, increase UV ultraviolet lamp adjustable Angle adjusting device, peak value of 254 mm, sterilization effect is the best product to stay under the sterilization lamp 1-3 minutes.
4. Equipped with automatic timer, may at any time to monitor the use time of the tubes, convenient lamp replacement.

5.This UV food sterilizer is a closed cabinet device made up of sterilizer drum, electronic control and cabinet body.

6.UV nuts sterilizing machine is made of excellent stainless steel which has a high reflection rate of the UV and produces no pollution during its use, complying with the sanitation requirements of food industry.

7. Inside the drum are UV lamp and quartz glass tube.

8.Based on the latest technology, to create a high effective disinfection unit for drinking water, we developed UIV series led uv sterilizer.

9. wide capacity for reaching different applications in industry and marine fields.

Advantages:

1. Concentrated design, instant sterilization speed is very fast;

2. Special designed ventilation system inside the light box;

3. The equipment is sterilized by four sides irradiation;

4. Stepless speed regulation of conveyor belt, stable and adjustable conveying speed;

5. Transmission net belt adjusting device can effectively prevent deviation;

6. Lamp abnormal protection device.

Equipment advantages:

1. Low temperature UV sterilization does not produce high temperature, sterilized products aseptic packaging;

2. The device is under full automatic zone control,

3. Instantaneous treatment to keep the original ingredients of the product

4. The sterilization area of the product is even, and the efficiency can reach 95%;

5. All round sterilization in sterilization area

6. The equipment is suitable for continuous long-time operation and production application

7. Long lamp life and low operation cost

8. It is easy to install, check and disassemble, and the pipeline maintenance is convenient

9. Reliable material, can withstand high product pressure

Equipment composition:

1. Material of machine: Stainless steel

2. Working inner chamber: One set of stainless steel plate

3. Machine body support: One set of Fangtong steel

4. Air conveying system: One set of forced air conveying combined exhaust fan

5. Exhaust device: Axial flow fan

6. Conveyor belt: Teflon mesh belt

Specification:
