Discharge width

 width 100-600MM

Coating width

 100-500MM

Glue feed

 gear pump

Hot melt tank

 with adjustable temperature cylinder

Coating thickness

 0.01-2mm

Rear film

 rubber coated roll

Discharge tension

 with adjustable tension control

Winding motor

 variable frequency motor

Winding diameter

 diameter 300MM

Coating speed

 1-50 m / min

Cooling device

 water cooling + air cooling

Equipment power

 220V Frequency, 50Hz

Equipment power

 3800W (heated state)

The whole process structure of the machine

 discharging (low material)---gluing---cooling---film---winding
