Model

FX8(2XZ-2B)

Geometric pumping speed m³/h(L/s)

7.2（2）

Nominal pumping speed m³/h(L/s)

8（2.2）

 Partial pressure Limit（Pa)

Gas ballast off

≤4X10^-2

Gas ballast on

≤8X10^-2

Ultimate total pressure (Pa)

Gas ballast off

≤5X10^-1

Gas ballast on

≤6X10^-1

Noise level Lw:dB(A)

Gas ballast off

62

Gas ballast on

65

Water vapor saturation pressure（Pa)

2000

Water vapor pumping rate（L/h)

360

Inlet diameter Φ

DN25ISOKF

Outlet diameter Φ

DN25ISOKF

Speed (r/min)

1400

Motor power rate（Kw)

0.37
