20L Material Pressing Machine

I. Equipment Features

Application Scope

Pressing and discharging materials from barrels using extrusion method.

II. Main Equipment Parameters

1. Matching Container Parameters

l Inner Diameter: 350mm

l Inner Depth: 300mm

2. Structural Type

l Cantilever frame

3. Lifting Mechanism

l None

4. Pressing Method

l Double-acting hydraulic cylinder drives the pressing plate

5. Discharge Method

l Bottom discharge

6. Functional Parameters

l Plate Size: Matches 350mm barrel

l Unit Pressure: 10kg/cm²

l Total Pressure: 9T

l Motor Power: 1.5 kW

l Pump Flow: 6 L/min

l Cooling Method: Air-cooled hydraulic station

l Control Method: Foot switch for up/down

7. Barrel Locking

l Mechanical locking

8. Barrel Transfer

l Manual

9. Other Notes

l Total Power: ≤2 kW

l Weight: Approx. 350kg

l Floor Load: 1000kg/m²

l Dimensions: L1000mm × W700mm × H1526mm

l Color: Off-white

III. Spare & Wear Parts List

IV. Supporting Conditions
