Sputter Coater for SEM Sample Preparation

Magnetron Sputtering Thin Film Deposition Coater For SEM preparation

  • Model Number:

    TMAX-ZK-JS01

  • Input Power:

    2000W

  • Compliance:

    CE Certified

  • Warranty:

    One Year limited warranty with lifetime support

  • Shipping Port:

    Xiamen

  • MOQ:

    1

  • Payment:

    L/C D/A D/P T/T Western Union

  • Delivery Time:

    5 days
Product Details

Magnetron Sputtering Thin Film Deposition Coater For SEM preparation





TMAX-ZK-JS01-Cold Magnetron Sputtering Coater

Product Highlights

· Uniform & Ultra-Fine Coating: Produces highly reflective/translucent decorative films with 6–10nm particle size, ideal for aesthetic applications.

· Cold Sputtering Technology: No surface temperature rise, ensuring integrity of heat-sensitive samples.

· High Efficiency & Precision: Wide sputtering current range (5–45mA) with 600V voltage and up to 450W power for dense, adherent films.

· Automated Operation: Features LCD control, auto-vacuum cycling (<90s pump-down), and gas release for streamlined workflows.

Key Applications

· Decorative Films: Full-reflective/semi-transparent coatings.

· Electrode Fabrication: Battery membranes, conductive layers.

· Electron Microscopy: FE-SEM sample preparation.

· Delicate Materials: Temperature-sensitive substrates (biological specimens, polymers, filters).

Technical Specifications

Category

Parameters

Operation Mode

Fully automated magnetron sputtering

Sputtering Current

2–50mA (adjustable)

Voltage

600V (adjustable)

Target Materials

Standard: Au/Pt (choose one); Optional: Ag, Cu, Al, Ti, Cr, Pb

Vacuum System

Oil-sealed rotary pump (1L/s) or optional dry scroll pump (<0.1Pa ultimate)

Chamber Size

Ø128×130mm

Sample Holders

1×Ø90mm, 4×Ø25mm, 6×Ø15mm

Gas Supply

Air/argon, auto-admitted via Φ4 quick-connect

Particle Size

6–10nm

Power Supply

220V/50Hz (110V customizable), 450W max

Protections

Over-current (>50mA cutoff), vacuum (>100Pa cutoff)

Unique Advantages

· Versatile Target Compatibility: Supports diverse metals for tailored film properties.

· Zero Thermal Damage: Critical for polymers, biomaterials, and battery components.

· Industrial-Grade Adhesion: Strong film bonding for durable decorative/functional layers.

Ideal for

· R&D Labs: Precision coating for SEM, thin-film studies.

· Manufacturers: Decorative films, electrodes, and sensors.

· Bio/Nano Tech: Delicate sample preparation with nanoscale control.

SEM Preparation Coater
