Single Side CNC Automatic Spot Welder with 5000A / 8000A Inverter DC Welding Power Supply / Transistor Welding Power Supply
Model Number:
TMAX-ZW-D100Type:
AutomaticInput Power:
2000WNet Weight:
200kgCompliance:
CE CertifiedWarranty:
Two years limited warranty with lifetime technical supportPlace of Origin:
ChinaUpdate:
OptionalShipping Port:
Xiamen PortPayment:
L/C D/A D/P T/T Western UnionDelivery Time:
5 days
- WhatsApp : +86 13003860308
- Email : David@tmaxcn.com
- Email : Davidtmaxcn@gmail.com
- Wechat : 18659217588
Previous:
Inverter DC Spot Welding Machine Suitable for Pure Nickel(less than 0.2mm or 0.25mm)Next:
Manual 18650 Lithium Battery Pack Assembly Line Project
Single Side CNC Automatic Spot Welder with 5000A / 8000A Inverter DC Welding Power Supply / Transistor Welding Power Supply
Performance Characteristics:
1. Touch screen display, more convenient operation and clearer display.
2. Three file programming modes, including manual input, array and CAD pattern import, can easily and quickly deal with various complex program editing.
3. The welding head has the function of air cooling or water cooling, which can effectively reduce the impact of the temperature of the spot welding needle on the welding quality.
4. It can store up to 99 groups of files, which is simple to call and does not need complex line change and machine adjustment process.
5. The spot welding procedure of side a and side B of the fixture can be switched.
Introduction:
Full automatic single-sided spot welding has strong flexibility. The machine head is driven by the cylinder for spot welding, with stable performance. It is suitable for the processing of various and diversified battery packs.
The fixture replacement is convenient and fast, the appearance is atmospheric and beautiful, and the all aluminum alloy body. There are two shapes for customers to choose from: one is the open fuselage without cover, which is more convenient for users; One is the fuselage with cover, translucent acrylic cover, high-end and high-grade, with stronger integrity, making the welding environment more quiet and comfortable.
Basic Parameters:
X-axis Travel |
500mm |
Y-axis Travel |
400mm |
Spot Welding Speed |
0.35s/point;2800pcs/h |
Maximum Speed of Motor Drive |
1000mm/s |
Maximum Number of Loaded Cells |
26 in X Direction and 26 in Y Direction (Standard 18650 Lithium Cell) |
Number of File Groups that can be Saved |
999 Group |
Operating System |
Embedded System + Man-Machine Screen |
Transmission Mode |
Stepping + Imported Precision Linear Guide Rail (Optional Servo + Screw) |
Equipment Power Supply |
Single Phase ~ 220V + 10% / 50Hz ±10% |
Equipment Air Pressure |
0.4~0. 7Mpa |
Equipment Weight |
200 KG |
