Chamber size (mm)

600×600×600 (W×D×H)

Nozzle material

SUS304

Diameter of spray hole

￠0.4mm

Spacing of spray holes

50mm；

Spray pipe diameter

φ16mm

Radius of spray ring

R375mm

Nozzle angle adjustable

120°(IPX3)、180°(IPX4)

Water pressure

Adjustable water flow as required

flow

1-7L/min；flow speed adjustable

Air velocity

1.0m/s

Test time

0-999min adjustable

Swing angle amplitude of swing tube

±45°、±60°、±90°、±180°（adjustable）

Pendulum tube

It is driven by servo motor, with high precision and accurate time and swing

Water supply pipeline

PPR pipe is used for equipment water supply, which is arranged according to box distribution and controlled by equipment control system cabinet

Heating mode

Adopt stainless steel heating pipe, shallow water plate surface evaporation;

Spray cycle

The spray cycle in the box is adjustable, and the door is equipped with an observation window to observe the state of the sample in the box. Window wiper installed
