Precision Supercapacitor Tab Riveting and Forming Machine

MSK-PN120 is a compact gas-driven Aluminum Laminated Films pouch case forming machine for pouch cell fabrication laboratory. To ensure continuity and compatibility for customer's research, MSK-PN120 fits the electrodes cut by  electrode cutting machine. The adjustable depth (spacers set is included in standard package) allows the formed case to fit electrode stacked in different height.

Automatic CNC Riveting Machine With Rotary Table

Automatic CNC Riveting Machine With Rotary Table   Feature The workbench is used to place workpieces (the width of the workbench surface can be customized according to customer requirements), which is more efficient. Precise positioning of the XY working platform Teaching programming is simple to operate It is equipped with an electronic handwheel for convenient machine adjustment One-time training, storage and invocation, convenient and fast Three different specifications of rivets can be automatically inserted at one time Teach the preset riveting points and automatically rivet them one by one. The height of the riveting head is automatically adjusted for riveting points of different planar heights. For rivets of different sizes, different riveting times are set separately to achieve the maximum riveting quality and the best riveting efficiency. A specially designed forced pneumatic material ejection device is provided to easily complete the product discharge. For the riveted workpieces, it has a code storage function. When used for the second time, only the data needs to be directly called up. For the riveted workpieces, it has a code storage function. When used for the second time, only the data needs to be directly called up. The positioning is driven by imported Japanese servo motors, which are precise, stable and durable. The 10-inch color human-machine interface display makes operation more intuitive and easy.   Workflow 1. Start up the machine, return the system to zero, and move the worktable to the clamping position. 2. At the clamping position of the equipment, the operator places the cylinder head cover part on the positioning fixture and quickly clamps the workpiece manually. 3. Start the equipment, and it will automatically feed the positioning fixture and workpiece to the first riveting position and lock them (achieved by motor phase locking). 4. The riveting head descends for riveting (the descent distance can be set); 5. Single-point riveting is completed when the riveting head descends to the set riveting position. 6. Control the action of the riveting cylinder and retract (the retract distance can be set); 7. Move the workpiece and fixture longitudinally and laterally to the next riveting point. 8. Repeat steps 4 to 7. After riveting is completed, the equipment automatically moves the positioning fixture and the workpiece to the manual operation position. 10. Complete one riveting operation

1T Desktop Pneumatic Riveting Machine

1T Desktop Pneumatic Riveting Machine   Technical parameter Name Pneumatic Riveting Machine Throat depth 200MM Pressure 1T Mechanical dimensions 800X550X1500 Mechanical weight 150KG Customization support Yes The suitable rivet pipe diameter 2.5 to 4 millimeters The suitable rivet length 3 to 30 millimeters

Automatic Electric Pneumatic Bag Flat Riveting Machine

Automatic Electric Pneumatic Bag Flat Riveting Machine   Introduction This machine adopts the principle of combining electric and pneumatic power to complete the riveting of workpieces. The processing operation is smooth, without impact or noise, with precise positioning and a smooth and flat processing surface. The rivets are fully automatically fed with high precision. Strong stability. The riveting speed can reach 60-65 per minute, with high working efficiency and an attractive and beautiful appearance. It is applicable to riveting of products such as leather bags, handbags, paper bags, paper cards, belts, shoes, tents, hats, stationery, flexible circuit boards and hardware. Safe and reliable, time and labor-saving, with a wide range of applications. Features Low noise Due to pneumatic transmission, there is no noise pollution. Simple operation Just step on the foot switch (two-hand buttons can be added for operation), and it will automatically rivet.   Short riveting time It can be adjusted within 0.1 to 10 seconds. Counter Electronic counter for convenient statistics of product output Good processing quality Due to the adoption of a special mechanism, the pressed surface is both smooth and accurate, and will not deform. Wide application range Different molds can be used to press different products.

Small High Precision Servo Orbital Riveter Machine For Soft Steel Riveting

Small High Precision Servo Orbital Riveter Machine For Soft Steel Riveting   Feature Inovance high-performance servo motor + Inovance or Mitsubishi PLC TBI high-precision lead screw or optional THK high-precision ground lead screw from Japan Weilun 7-inch high-definition touch screen Schneider contactors, push-button switches Mingwei power supply, Omron photoelectric switch High-precision and high-flexibility riveting chucks The self-developed intelligent control system has a repeatability accuracy of up to 0.01mm   Technical parameter Riveting ability Solid φ1-3mm(soft steel) Hollow φ2-5mm(soft steel) The length of the rivets 5-100mm Deep throat 125mm Stroke Max 80mm Power 0.4KW AC220V/50Hz 0.75KW AC220V/50Hz Working pressure 1800N(180Kgf) Dimension 380*460*750mm Working area 230*250mm Net weight 86kg

Air Press Orbital Riveting Machine With Foot Pedal For Hardware Parts Riveting

Air Press Orbital Riveting Machine With Foot Pedal For Hardware Parts Riveting   Application It is applicable to various hardware accessories, mechanical parts, sports equipment, travel products, hardware tools: such as the riveting of solid rivets or hollow rivets with pliers, etc   Technical parameter Riveting ability Solid φ1-6 mm The length of the rivets 150mm Deep throat 120mm Horsepower 1/2HP Maximum pressure 200-800kg Mechanical height 940-1050mm Working area 190*320mm Net weight 120kg

Oil Press Orbital Riveting Machine With Two-Stage Height Adjustment System

Oil Press Orbital Riveting Machine With Two-Stage Height Adjustment System   Introduction The steel plate body is sturdy in structure with a low center of gravity. It is equipped with a two-stage height adjustment device and a large cooling system, which makes the oil temperature less likely to rise and the pressure less likely to decline. The two-stage speed design of the chuck stroke ensures higher production capacity. It has a large output force and strong riveting ability, with the maximum strength of rivets reaching up to 20mm.   Technical parameter Riveting ability Solid φ3-20 mm The length of the rivets 400mm Deep throat 200mm Horsepower 5HP Maximum pressure 1400-5500kg Mechanical height 1800mm Working area 160*260mm Net weight 580kg

Automatic Servo Orbital Riveting Machine With XYZ Positioning Axis System

Automatic Servo Orbital Riveting Machine With XYZ Positioning Axis System   Application It is suitable for riveting products with multiple rivets, at different positions and heights, but with consistent appearance and similar size. Automatic riveting of solid or hollow rivets at multiple points for hardware components in industries such as automotive parts, precision electronics, sheet metal shafts for movements, and hardware tools.   Features The body features a humanized design and an attractive appearance. Huichuan high-performance servo motors and PLC control are precise. Taiwan TBI high-precision lead screw feed, with a repeatability accuracy of up to 0.02mm. The Weilun 10-inch high-definition touch screen offers a clear field of vision and is easy to operate. High-precision and high-flexibility riveting chucks offer better riveting effects. With up to 50 coordinate riveting points set on the XY axes, multiple products, multiple riveting points, and riveting at different heights can be achieved at once, doubling the efficiency.   Technical parameter Riveting ability Solid Φ3-10mm (soft steel) Z-axis travel MAX 80mm Opening height 210mm X-axis travel 800mm Y-axis travel 400mm Power 1.0Kw AC220V/50Hz (Rotary motor) 2*1.8Kw AC380V/50Hz (XY-axis motor) 2.4Kw AC380V/50Hz (Z-axis motor) Maximum working pressure 30KN(3000kgf) Area of the mobile workbench 500*500mm Overall dimensions 1380*1680*1890mm(L*W*H) Net weight

Automatic Servo Orbital Riveter Machine With XY Positioning Axis System For Multiple Rivets Riveting

Automatic Servo Orbital Riveter Machine With XY Positioning Axis System For Multiple Rivets Riveting   Application It is suitable for riveting products with multiple rivets, at different positions and heights, but with consistent appearance and similar size. Automatic riveting of solid or hollow rivets at multiple points for hardware components in industries such as automotive parts, precision electronics, sheet metal shafts for movements, 3C electronics, and hardware tools.   Features The body features a humanized design and an attractive appearance. High-performance servo motors and precise PLC control; High-precision lead screw feed with high repeatability accuracy, up to 0.01mm. Weilun 7-inch high-definition touch screen, with clear field of view and convenient operation; High-precision and high-flexibility riveting chucks offer better riveting effects. With up to 50 coordinate riveting points set on the XY axes, multiple products, multiple riveting points, and riveting at different heights can be achieved at once, doubling the efficiency   Technical parameter Riveting ability Solid Φ1-5mm (soft steel) Itinerary MAX 70mm Rivet length 1-70mm Deep throat 250mm "Power" 0.4Kw AC220V/50Hz (Rotary motor) Maximum working pressure 3*0.75Kw AC220V/50Hz (lead screw motor) Workbench area 8KN(800kg) Overall dimensions 230*380mm Net weight 800*685*1780mm(L*W*H)

Automatic Double Workstation CNC Servo Riveting Machine

Automatic Double Workstation CNC Servo Riveting Machine   Features The workbench is used to place workpieces (the width of the workbench surface can be customized according to customer requirements), which is more efficient. Automatically rivets each preset riveting point one by one. The height of the riveting head is automatically adjusted for riveting points of different planar heights. For rivets of different sizes, the riveting time is automatically adjusted to achieve the maximum riveting quality and the best riveting efficiency. A specially designed forced pneumatic material ejection device is provided to easily complete the product discharge. For the riveted workpieces, it has a code storage function. When used for the second time, only the data needs to be directly called up. For the riveted workpieces, it has a code storage function. When used for the second time, only the data needs to be directly called up. The positioning is driven by imported Japanese servo motors, which are precise, stable and durable. The 8-inch color human-machine interface display makes operation more intuitive and easy.   Technical parameters 1) X-axis working range: Max. 500MM. 2) Y-axis working range: Max. 300MM 3) Positioning accuracy: 0.1MM 4) Repeatability accuracy: 0.05MM 5) Number of NCS: 3 axes 6) Z-axis movement range: Hydraulic stroke: 30mm, numerical control stroke: Max.150mm. 7) Program capacity: More than 100 sets. 8) Processing points: More than 100 points. 9) Positioning: 2-axis linkage, with manual control for the movement of the X, Y, and Z axes. 10) Workpiece positioning: Manual positioning. 11)X, Y speed: Maximum 400MM/S 12) Lead of X and Y lead screws: 10MM; Z-axis lead screw lead: 5MM 13) Monitoring signal: Touchscreen display 14) Fault display: Touchscreen display 15) Teaching box: Make your own teaching box 16) Programming method: Teaching demonstration
