die-cut
  • electrode cutting machine Precision Die Cutter for Pouch Cell electrode Sheet

     Precision Die Cutter for Pouch Cell electrode Sheet TMAX-MQ280 is a CE Certified Precision electrode die cutter with optional size range). It is a necessary tool in the production line of pouch cell to produce specific shapes of cathodes and anodes with current collector tabs. The size of the electrodes it cuts perfectly matches the standard pouches made by the TMAX-SCK200  cup forming machine, and the shape of the electrodes it produces is also handy for the latter processing steps. The IR sensor (Safety Curtain) built in the front of the machine ensures operation safety when electrode sheets are fed from the front.

  • Automatic Punching Machine Automatic Die Cutting / Punching Machine For Anode and Cathode Electrode

    Automatic Die Cutting / Punching Machine For Anode and Cathode Electrodefor Stacking Pouch Cell SPECIFICATIONS This machine is used for make the roll electrode into cell shape electrode automatically. 1 Roll electrode feeding automatically, controlled by Photoelectric switch 2 Adopt laser module to get high efficiency and accuracy

  • Battery Die Cutting Machine Battery Automatic Die Cutting Machine For Aluminium And Nickel Cutter

    1 TMAX-NC-100 Nickel Cutting Machine is mainly used for all kinds of metal and no-metal strip materials, such as  copper foil, aluminum foil, copper foil tape, batteries nickel belt and so on. 2 For mobile phone battery pack, it used for for the Nickel cutting with lower cost than formed size Nickel chips.

  • Electrode Slitting Machine Battery Electrode and Separator Slitter Slitting Machine

    Electrode Slitting/Cutting Machine For Sale The slitting machine TMAX-MSK-300 is a CE Certified semi-automatic slitting machine (roll slitting) for preparing electrode of cylinder batteries in R&D laboratories.

  • Die Cutting Machine Semi-automatic Pouch Cell Battery Electrode Die Cutting Machine

    1 TMAX-MQ300 semi-automatic electrode die cutter is mainly used for pouch cell electrode sheet cut for stacking pouch cell battery. It is a necessary tool in the production line of pouch cell to produce specific shapes of cathodes and anodes with current collector tabs.   2 This Semi Automatic Die Cutter machine adopts Safety Curtain built in the front of the machine and double start button ensures operation safety when electrode sheets are fed from the front.   3 High speed, high accuracy, long lifetime to make cutted electrode without burr, to get a good consistency.   4 This model has max die dimension with 200*300mm, if need other models, please choose the TMAX-JD-500model with max die size up to 500*500mm.

  • Electrode Die Cutter Lab Electrode Die Cutter for Pouch Cell electrode Sheet with Two Size Range Optional

    1 TMAX-MQ300 semi-automatic electrode die cutter is mainly used for pouch cell electrode sheet cut for stacking pouch cell battery. It is a necessary tool in the production line of pouch cell to produce specific shapes of cathodes and anodes with current collector tabs.   2 This Semi Automatic Die Cutter machine adopts Safety Curtain built in the front of the machine and double start button ensures operation safety when electrode sheets are fed from the front.   3 High speed, high accuracy, long lifetime to make cutted electrode without burr, to get a good consistency.   4 This model has max die dimension with 200*300mm, if need other models, please choose the TMAX-JD-500model with max die size up to 500*500mm.

  • Electrode Die Cutter Battery Electrode Die Cutting Machine for Pouch and EV Cell Production MSK-180

    MSK180 is a CE Certified semi-automatic electrode die cutter. It is a necessary tool in the production  line of pouch cell to produce specific shapes of cathodes and anodes with current collector tabs.

  • Pouch cell Die Cutter Lab Electrode Die Cutter for Pouch Cell Electrodes

    TMAX-180S is a gas driven die cutter for producing pouch battery cathode/anode electrodes ( no electricity required ) Its compact design enables the operation inside a glove box with Ar atmosphere where moisture/oxygen-sensitive electrodes will be cut

  • Die Cutting Roll To Roll Electrode Die Cutting Machine

  • Automatic Pouch Cell Die Cutter Automatic Pouch Cell Die Cutter for Battery Electrode

  • Electrode Die Cutter Lab Electrode Die Cutter for Pouch Cell Electrodes Cutting

    MSK-180S is a gas driven die cutter for producing pouch battery cathode/anode electrodes ( no electricity required ) Its compact design enables the operation inside a glove box with Ar atmosphere where moisture/oxygen-sensitive electrodes will be cut

  • Electrode Die Cutter Double Servo High Speed Automatic Die Cutting Machine for Pouch Cell

    MSK-180S is a gas driven die cutter for producing pouch battery cathode/anode electrodes ( no electricity required ) Its compact design enables the operation inside a glove box with Ar atmosphere where moisture/oxygen-sensitive electrodes will be cut

  • Electrode Die Cutter Automatic Double Servo High Speed Die Cutting Machine

    MSK-180S is a gas driven die cutter for producing pouch battery cathode/anode electrodes ( no electricity required ) Its compact design enables the operation inside a glove box with Ar atmosphere where moisture/oxygen-sensitive electrodes will be cut

  • Electrode Die Cutter Automatic Double Servo High Speed Die Cutting Machine

    MSK-180S is a gas driven die cutter for producing pouch battery cathode/anode electrodes ( no electricity required ) Its compact design enables the operation inside a glove box with Ar atmosphere where moisture/oxygen-sensitive electrodes will be cut

  • Hydraulic Electrode Die Cutter Lab Hydraulic Electrode Die Cutter for Pouch Cell Electrodes Cutting

    Lab Hydraulic Electrode Die Cutter for Pouch Cell Electrodes Cutting Introduction This product is suitable for die-cutting and forming of battery anode and cathode sheets, as well as for die-cutting of lithium chips, and can be used in a glove box. Main features *Small size, easy to operate, can be placed in a glove box for operation. *Built-in safety overflow oil valve, the pressure can be adjusted according to needs, and the upper limit of the pressure can be set to prevent damage caused by excessive pressure caused by misoperation, ensuring the safety of the machine. *Built-in pressure gauge can observe and accurately control the sealing pressure. *Using hydraulic drive, the pressure can reach 8T, die-cutting without vibration and leakage. *It is convenient and quick to change the knife mold; * Long tool life, normal use ≥ 30,000 times; *No quality defects such as burrs, powder falling, and indentation; *Adopting four guide pillar structure, sliding up and down smoothly and high precision; * Beautiful appearance, easy maintenance, small size, convenient operation, accurate molding, etc. Instructions Put the electrode sheet into the die-cutting position, and then hold the oil unloading valve handwheel, tighten it in a clockwise direction, and rotate it to the limited position. Pry the hand rocker up and down continuously, when the jack rises and pressurizes, the movable template drives the die-cutting knife group to automatically cut the electrode sheet into shape. Hold the oil unloading valve hand wheel and unscrew the electrode sheet by half a turn counterclockwise. The mold will automatically open and take out the electrode sheet to complete. Specification Max. Punching size 120mm*100mm(can be customized as requirement) Punching accuracy ±0.1mm Max. pressure 8T Die cutting stroke 35mm Structural material High-strength chrome steel, the surface will never rust after environmental protection plating and spraying Dimensions 223mm*170mm*325mm Weight 25kg
